Initial operation procedure

When connecting the telephone system, the local regulations must be observed.
1. Connect the extensions (1...8) in
correspondence with the connec-
tion diagrams.
2. Plug the AC adaptor into the power
outlet.
3. Plug the CO line in the telephone
wall socket.
The telephone system is now ready for use. When you pick up the handset of an extension you
will hear the telephone system's dial tone. When you dial 0 you will hear the continuous dial
tone of the CO line.

Factory pre-set

When delivered and after a reset, the telephone system has the following configuration:
No. Functions
1 automatic CO-line access
2 CLIP presentation at the telephone
3 SMS-port external line 1
4 SMS-port external line 2
5 call transfer
6 do-not-disturb function
7 music-on-hold external line 1
8 music-on-hold external line 2
9 call waiting
10 day / night
11 call external line 1
12 access external line 1
13 call external line 2
14 access external line 2
15 long-distance calls authorised
16 dialling restrictions/call blocking
17 door opener duration
18 direct connection with door intercom
19 door bell ring authorisation
20 door opener authorisation
Extension 1 and extension 2 (2/8 clip only)
must always be connected, because in the
case of a power failure (or if the AC
adaptor is disconnected) it continues to
function.
In addition, the special features of the tele-
phone system can be programmed from
extension 1.
D, A, B, CH, F, NL
all OFF
all ON
OFF
OFF
OFF
OFF
ON
ON
ON
day
all ON
all ON
all ON
all ON
all ON
all OFF
3 s
all OFF
all ON
all ON
8
Portugal
all ON
all ON
OFF
OFF
OFF
OFF
ON
ON
ON
day
all ON
all ON
all ON
all OFF
all ON
all OFF
3 s
all OFF
all ON
all ON
