Programmable parameters
Setting the SMS extension for CO line 1
Example: configuration of extension 21 for a SMS device for external line 1
1. Pick up the handset of extension
21 .
2. Enter the program code number
19999 .
3. Dial the code number 39 n.
n = 1...8: this is the last digit of the
SMS extension.
Example: dial the code number 391
for extension 21 .
Please make sure that only the external line 1 will be signalled at the selected extension (in
this case 21) and that this extension realises the access to the CO-line only via external line
1. To do this, it is possible to use, for example, the targeted CO-line access with "94" instead
of "0". Generally, it is recommended to carry out a clear and unequivocal assignment:
1. For the activation of the CO-line
ring for external line 1, dial code
number 311 .
2. For the deactivation of the CO-line
ring for external line 2, dial code
number 341 .
3. For the activation of the CO-line
access for external line 1, dial code
number 211 .
4. For the deactivation of the CO-line
access for external line 2, dial code
number 241 .
5. Replace the handset of extension
21 .
You hear the dial tone of the telephone
system.
You hear the acknowledgement signal.
The connection for the SMS-device is pro-
grammed.You hear the acknowledgement
signal.
You hear the acknowledgement signal.
You hear the acknowledgement signal.
You hear the acknowledgement signal.
You hear the acknowledgement signal.
Programming is terminated.
