TIPTEL 1/8 fax clip Operating Instructions Manual page 36

Programmable parameters
Incoming external calls will sound with the CO line ring. This ring can be individually switched
On or Off for each extension.
To switch the CO line ring on or off
1. Pick up the handset from extension
21.
2. Dial the program code number
19999 .
3. Dial the code number for the desi-
red state of CO line ring according
to the table below. For ex. 323 to
switch Off the CO line ring of the
CO line 1 for extension 3. Several
code numbers can be entered one
after another.
4. Replace the handset.
Extension
CO line ring line 1 On
CO line ring line 1 Off
CO line ring line 2 On
for tiptel 2/8 only
CO line ring line 2 Off
for tiptel 2/8 only
* if the CO line ring is "Off" then extension 1 will ring as a safety measure
21 22 23
311 312 313
321 322 323
331 332 333
341 342 343
36
You hear the telephone system's dial tone.
You hear an acknowledgement signal.
As confirmation you hear an acknowledge-
ment signal.
Incoming calls from CO line 1 will no lon-
ger ring on extension 3. However, with the
call retrieval function 70 or call transfer it
is possible to receive an external call.
If the ring is switched Off for all extensions,
then extension 1 will automatically ring as
a safety measure.
The programming is finished.
24 25 26
314 315 316
324 325 326
334 335 336
344 345 346
27 28 all*
317 318 310
327 328 320
337 338 330
347 348 340
