D Sound module USM-RC-2
Configuration - SM-IR-16-2
Both servo outputs of the light module SM-IR-16-2 can be configured similar to the
servo outputs of the sound module.
For details about the settings please read page 71 onwards. The only difference is
that the SM-IR-16-2 has only 2 positions, #1 and #2. The positions #3 and #4 do not
exist here.
The two servo outputs of the SM-IR 16-2 can also be directly (stepless) controlled via
one of the four proportional inputs of the USM-RC-2. The proportional signal which
comes from the receiver is 1:1 forwarded via the IR transmission to the light module.
So you can, for example, control a steerable axle of a trailer.
However, the proportional channel can only be used in this setting for controlling the
servos and not for any other function! In mixed mode you can use proportional
channel # 1, since this channel is not used.
