D Sound module USM-RC-2
If this option is not activated, the servo will not go back to home position during
deactivation, but rather stays in the current position. This means, any position can be
allocated to the servo. For this, the speed should be set relatively slow.
Sound at servo movement
If this option is activated, the additional sound for the servo will be played as long as
the servo is moving.
Sound when not in home position
With this function the additional sound will always be played, if the servo is not in
home position.
This version is very well suitable if you are using a speed controller with motor
instead of a servo. In home position (1,500ms) the motor is switched off and no
sound is played. For example, if position #1 is set to 1,800ms and you "select" this
position, the motor will turn and you can play a corresponding sound.
