beier USM-RC-2 Operating Manual page 65

D Sound module USM-RC-2
Configuration – Nautic mode
If you want to use the Nautic mode, you will first have to activate it here.
Switch assignment
Every switch position can be associated to a desired function (see page 39).
Depending on the function, a memory function for the corresponding switch can be
activated.
Attention!: It is not possible to use one function twice, therefore it is not possible to
activate the same function over two different switches.
Typ
Here you should select the type of your radio control system and your switch module.
Error correction
If problems occur in picking up the Nautic signal, at this point you can activate error
correction, as this may cause the Nautic switch transmission to operate more reliably.
Activating error correction does slow down the transmission of the switched state
slightly (approx. +200 ms) compared with operation without error correction. In
particular in the case of some 2.4 GHz transmitters it is advisable to switch error
correction on, as under certain circumstances incorrect switch positions are
occasionally transmitted, and this could trigger undesired actions.
Manual settings
Opting for manual settings enables you to set the values for the transmission protocol
of the Nautic mode manually. These values should only be altered as instructed.
Normaly it is not necessary to set the values manually.
03.02.2014 BEIER-Electronic 65
