D Sound module USM-RC-2

One-channel multi-function selection (EKMFA)

If "One-channel multi-function selection" (EKMFA) is activated, you can control up to
30 functions of the sound module using just one proportional channel, namely
channel #3 (see page 30). As in "normal" mode, the travel of the transmitter joy-stick
is divided into 5 areas A, B, N, C and D (see page 21). Of course you can use the
joy-stick simulation circuit from page 37, or other switches that are already fitted to
the transmitter, to control the functions in this mode.
Again, you can define in the Sound-Teacher which functions are triggered with the
EKMFA-mode (see page 66).
To trigger a particular sound or function, the transmitter joy-stick must be moved from
position N to position A or D for a specific number.
The last numerical value is always stored, enabling you to repeat the last sound or
the last function as many times as you wish, without counting once more. Simply hold
the joy-stick for 1 second in the position B, or C to repeat the last sound.
In order to switch the 12 outputs directly, they must be configured in the Sound-
Teacher as "static", "flashing" or "pulse". This way, an output that is configured
e.g. as reversing or brake light, cannot be switched on.
38 BEIER-Electronic 03.02.2014
