Selecting a COM port:
Defines on which port the unit
will be connected during the
initial installation.
Slider A, Slider B
Select here which functions you wish to assign
to the sliders of the two players. (Not with RCP-
2001-B).
Slider C
(Only RC V3) is the slider of the sample player.
Three functions are available: Sampler Pitch,
Sampler Volume, and Manual Fade A/B. When
setting as manual fader, crossfades between
player A, and player B can be performed even
without external mixer.
Switches A, B, C
Define here the functions of the multi purpose
buttons of the two players. (Only RC V3) These
settings also apply for the two players in the
program!
Adjust Sliders
Activate this option when you have problems with
the sliders. (Only RC V3)
Text Scrolling
Activates title scrolling in display
(Needs some system resource)
Level Meters
(only RC V3) Shows level indicator in RC display.
(Uses some system resource)
Activate this checkbox if a
external mixer is connected
to the fader start socket [36] or [37], and the
players should be started automatically when
blending in a particular channel (Only RCP-1001
/ 2001)
Activate this checkbox if a
external mixer is connected
to the fader start socket [36] or [37], and the
players should be stopped automatically when
blending in a particular channel. Should this
checkbox stay activated, the players will keep
playing, even if the mixer controls are pulled down.
(Only RCP-1001 / 2001)
Activate this option if you
would like to use the pulse
start socket of the remote control unit. (Only RCP-
1001 / 2001)
(only RC V3) With this button the
remote control unit sliders are
calibrated. To do so place the 3 sliders into their
center position and click on CALIBRATE. The
slider position will be defined to 0.
Program Options
