With the file editor it is possible to cut sequences
out of a file, or to set cue points with single beat
accuracy. All applied settings like volume, pitch
control, cue in, and cue out will be detected by
the players and applied, and can also be saved
in Play Lists.

3.11.1. Loading and displaying a Title

When loading an audio file for the first time,
initially, peaks will be created, and saved.
This procedure does not make any changes to
the file, it remains in it's original condition. Peaks
will be stored on the local hard drive. In program
options, you can define if these peaks are to be
deleted after your done working with the program
(more storage efficient), or if they should be saved.
(More time efficient)
Once loaded the file will be graphically displayed.
The field editor consists of two windows, of which
the lower one always displays the file in it's whole
length. This way you always have a complete
overview of the file, and are able to quickly
navigate within it. The top window is used to edit,
set cue- start- and endpoints, or to select a certain
area for export to a file.

3.11.2. Adjusting Display Range

There are two ways of modifying the top part of
the window:
Either adjust
the width, or
move the
area bar back
and for th
between the

File Editor
