Sample Editor

The sample editor allows editing of all 9 channels
of the sample player. It is possible to make
adjustments like LOOP, VOLUME, PITCH FADE
IN, and FADE OUT.
The nine channels form a sample block, in which
any number, or all adjustments can be saved
as*.SMP-file by using the

3.08.1 Sample Block Functions

The buttons, located at the window's bottom, refer
to the whole sample block.
Opens a dialog box for loading
of previously saved sample
blocks
Opens save dialog box
button.

3.08.2 Sample Channel Functions

Following settings will be adjusted for each
sample individually:
Deletes all files in the open
sample block
Adopts all current settings, and
closes the editor window.
Closes the sample editor,
discarding all current settings
When LOOP function is active, (see also
sample player pop up menu) the sample
will be played in an endless loop.
