RCP-2001 Description
[37] Remote start input (P. START)
This input works with mixers through the Remote
Start function (or Puls Start). An example would
be some of the BEHRINGER models. Both
players will be controlled using one contact.
Connections to the mixer are mostly
accomplished through a ¼ inch - mono jack.
Connection to the BPM Studio Remote Control
Unit RCP-1001 by the RCP-2001 can be made
through a 1/8-inch stereo jack. So, please use an
adapter connecting the 1/8-inch stereo jack to ¼
inch - mono jack. Remote Start Input has to be
chosen in the program options (index card
„Remote Control", Checkbox „Puls Start"). Finally
you can activate Fader-Start and Fader-Stop.
How it works:
Player A is started by locking contact A and is
stopped by locking it once more. The same is
valid for Player B and contact B. Through program
options you can activate fade start and also stop
separate fade.
[38] Serial cable socket
Connect the (9-pin, Sub-D) plug of the Remote
Control Unit with the supplied serial cable to your
PC. The maximum length of cable that can be
used is 49.2 feet (15 m), however we do not
recommend using more than 32.8 feet (10 m).
Another socket to connect power supply and
serial connection is on the left side of casing. This
makes it possible to use Remote Control Unit also
as table device without bothering plugs on the
back side of device. To use it you need a special
cable, which is available from your local
ALCATech dealer or directly from ALCATech.
[39] Power supply socket
Connect delivered power supply cable (12 V, at
least 1 A) to this socket.
