RCP-2001 Description
[22] Tempo Button
Press this key to change the playback speed
without modification of the pitch. The TEMPO -
LED [23] indicates the Master-Tempo function.
Attention! The pitch range changes when closing
the Master Tempo function. Please also read the
information contained in chapter Player of this
manual.
[23] TEMPO - LED
Is lit if the Master Tempo function is active.
[24] Pitch Button
Using this key, you can deactivate the settings of
the playback speed via the [Pitch slider] [10].
[25] Pitch-LED
Is lit if the Pitch or Master Tempo function is active.
[26] BRAKE-LED
Is lit if the function BRAKE is active. If BRAKE is
in progress, then this LED is blinking.
[27] BRAKE Button
The BRAKE function simulates braking down to
0 or the push of a turn-table. The effect is triggered
if the BRAKE light is on and the title is started or
stopped using the [PLAY] button [5]. Once the
breaking effect of the title has started you can
slow it down or stop playing by using the internal
Jog Wheel disc.
[28] Sample Player [1] to [9]
Using these keys you can start the Samples to 9
of the BPM Studio Sample Player. Read section
Sample Player in this manual about different
possibilities of working with samples.
[29] Sampler-Status-LED
3 colors LED display shows the Sample Player
status. If the green light is on, then Sample Player
is ready to work. Orange light indicates that
Scratch mode is ready. Red light indicates that a
file is loading into the Sampler Player. During this
time no sample can be played.
[30] Sampler Control and Preview
Player's Control
With both and
output of the Sample Player to Player A or Player
B. It is only necessary when no own
sound card channel is assigned or only two output
channels are at disposal (according to the
hardware and software configuration of your
system). [0] key stops playing all samples.
Preview Player's Control:
If the Sample Player is in Pause mode, that
means, if no sample is played, you can start the
Preview Player of the File archive using the [0]
key. Now, the selected title will be played via the
monitor channel and can be heard irrespectively
of the running program. In this mode, the
and keys work as fast forward and fast
reverse.
[31], [32], [33] Fade Control
(not active in the BPM Studio LE)
These three keys adjust the automatic Cross
fader.
[AUTO] [31] switches Auto-fade mode on or off.
If the Auto-fade mode is activated then this key
shines in red.
By the [FADE] key [32] you apply the set fade
process to the current title. This key blinks in red
as long as Cross fader is on and both Players
run. Using the [MODE] key [33] you can switch
between 6 different fade process presets. The
current running fade process will be deleted.
keys you can assign
