[14a] Indicates the number of loaded Tracks
[14b] NEXT TRACK indicator.
(Not active by RCP-1001)
[14c] Displays the time. Playtime of the title is
shown in minutes, seconds and in tenth of
seconds. Time information can be switched over
by using the [TIME] key [19] between total title
play time (ELAPSED), remaining title play time
(REMAIN) and total remaining play time of the
playlist (TOTAL). If the Player is in Cue mode,
then the current Cue-Point will be shown.
[14d] Operation mode of the time display,
switchable by the [TIME] key [19]
[14e] BPM value indicator, here the display will
show BPM value taken from the ID3-Tag of the
loaded title or value of real time BPM Counter.
[14f] Displays Pitch value in percents.
[14g] Displays the Pitch mode type. According
to the chosen mode in the program panel, you
will see if the changes of speed will work with or
without change of the sound level (Master-
Tempo).
[14h] Displays the mode of Jog Wheel. Using the
Archive [16], [17] keys it is possible to switch
between operation modes of the Jog Wheels.
indicates File Archive Mode,
indicates the Playlist Archive Mode and the
Search Mode (standard operation
mode).
[14i] Bar indicator displays the current play
position
[14k] The title display shows the current loaded
title and the interpreter from ID3- Tag of the MP3
file. The display scrolls automatically when data
cannot be completely presented. If you
experience problems with the performance of your
system, title scrolling can also be turned off in
the program options of the Remote Control Unit.
This display can be also used to show a lot of
supplementary information. In the archive mode
for example, the respective selected group,
Playlist or the title in archive will be displayed here
temporary.
[14l] Displays the four additional functions: Single-
/Continous-Play, Shuffle
Programming can be done using the [MODE] key
[20] and [SET] key [21].
[14 m] Display for the Loop-Sampler
(not active in BPM Studio LE or RCP-1001)
[16], [17] Archive Keys
Using the [ARCHIVE] [16] key you can switch
the Jog Wheel [1], [2] into the File Archive Mode.
It is indicated additionally in the display by symbol.
The [P.List] key [17] switches to the Playlist
Archive mode. By pressing the key again the
Search mode will be switched back (switching
back takes place automatically as well, when any
other key of the Player is pressed or after 30
seconds, if you have not moved the Jog Shuttle
Wheel during this time).
[19] Time Button
Using this button you can switch the play time
indicator in display [14] between total play time
(ELAPSED) and remaining time of title (REMAIN).
(TOTAL is not supported at present)
[20] MODE Button
By this button you can program four additional
functions: Single-/Continous-Play, Shuffle and
Repeat.
By pressing this [MODE] button multiply you can
select one of the modes. Corresponding indicator
will blink in display [14].
RCP-1001 Description
and Repeat.
