Control elements on the front side
of device:
[1] [2] Jog Shuttle Wheel
The Jog Shuttle Wheel allows you to use a lot of
the BPM Studio functions easily and
ergonomically. The external ring [1] and the
internal disc [2] are working touch sensitive. If
the ring is moved further i.e. if the internal wheel
is moved more quickly so the parameter
modification of the player will be made more
quickly. Jog Shuttle Wheel have 3 operation
modes: Search, Cue und Archive mode.
Jog Shuttle Wheel in Search Mode:
This is the standard mode which is active during
play of any title. Search Mode will be shown in
the Display [14] by symbol
influence the play back of the loaded or played
title with the wheel.
You can move the loaded title forward or in the
reverse direction using the external ring.
According to the turn angle of the ring [1], there
are 3 different search speeds available (+1, +2,
+3 or -1, -2, -3) and step mode where you can
play the title in 1 minute steps (+min or -min).
Using the internal disc [2] of the Jog Shuttle Wheel
this title will slow down or accelerate. It works
also when title slows down straight by BRAKE
function or on start-up.
Jog Shutter Wheel in Cue Mode:
If the Player is in Pause Mode, then a Cue Point
can be set exactly with the internal disc [2]. If the
Player is stopped and the disc will be moved by
one step, then the Player goes into this mode
and 160 ms of the current play position will be
played repeatedly as Loop. This position can be
now positioned exactly before the next Beat.
Changes of the Cue-Point are taken over by
pressing the Cue key anew.
Beat-Stepping:
If in the Cue mode the [ LOAD] key [11] is
additionally held down, then you can move exactly
step-by-step forward or backwards to a Beat in
the title. Read chapter "Beat Stepping using the
BPM Studio" too.
. You can Jog Shuttle Wheel in Archive Mode:
In the Archive mode you can comfortably navigate
in File Archive or Playlist Archive using this wheel.
You can switch into the appropriate mode using
[Archive] or [P.List] keys [16], [17]. The archive
mode is shown in the display by the symbols
or
left part of archive window using external ring [1].
Once more you can choose from four different
Scroll speeds. -1 or 1 switches exactly one group
further or back. +2/+ 3 or -2/-3 present two
different search speeds in the list with the groups.
+min/-min finally moves the selcetion bar to the
beginning or to the end of the list.
A group will be opened if you stay longer than
one second on a group using the selection bar.
Then, you can select the subgroups using the
Jog Wheel. Now in this case you can load the
complete group into Playlist by pressing the
[LOAD]- key [11].
You can also select any title from the group using
internal disc [2]. Loading may be made also by
[LOAD]- key [11]. By a simple click, the title will
be loaded into Playlist after the marked position.
RCP-1001 Description
. Choose the desired group in
