RCP-1001 Description

Remote Control Unit RCP-1001 is a simple
version of the RCP-2001 with a limited functions
range. It works with the BPM Studio Professional
und with BPM Studio LE ex Version 4. Besides of
very clear VFD displays, it is equipped , exactly
as RCP-2001, with Track Selector and Jog Shuttle
Wheels as well. It allows among other to choose
directly the titles of the file archives (only BPM
Studio Pro software). If external Remote Control
Unit is logged-on in the program options, then
program examines during start up, if the Remote
Control Unit is connected and operative.
Installation
(Please, read the instructions on how to connect
the Remote Control Unit on page 12 and
instructions how to run the program for the very
first time on page 13).
Connect [REMOTE/PC] [38] socket of Remote
Control Unit using the supplied cable to a serial
port (COM1 or COM2) on your computer. Power
supply is given by delivered power adapter.
Following settings should be made:
COM1 / COM 2
Select to which COM portthe Remote Control Unit
is connected
RC Active
Select this check box to inform the program that
a Remote Control Unit is connected. Every time
the program is started it will check, if Remote
Control Unit is connected and operative.
Operation
The Remote Control Unit contains a controller
for both Player A and B. The basic functionality
is the same as described in the section of the
manual dedicated to the player. When the pro-
gram finds an external Remote Control Unit during
its startup and the Remote Control Unit has the
pitch button activated, then the pitch slider of both
players in the program are locked. Only the
external Remote Control Unit can change the
pitch. The slider on the screen shows merely the
position of the slider on the Remote Control Unit.
Using the Remote Control options tab in the pro-
gram options, you can program the slide bars.
They are adjustable by either Pitch or volume. If
you are using the notebook version, it is also
possible to mix without an external mixer. The
Pitch setup will be taken over by the software.
