[49], [50], [51] Universal keys
The universal keys can be verified in the program
options, section Remote Control , every time as
described below:
The A [49] key: - Pitch range 1
- Player A Monitor
- Loop - Sampler Record
The B [50] key: - Pitch range 2
- Player B Monitor
- Loop - Sampler play
The C [51] key: - Pitch range 2
- CD Player Monitor
- Loop - Sampler Play
Fader start functions are only working with a
Remote Control Unit from Ver. 3.00 B. According
to the Remote Control Unit, connection of the
mixer (fade start enabled) via the Fader-Start-
Adapter (special accessory) or by the normal 3,6
mm stereo jack cable. Please pay attention to
the installation instructions in the chapters of
respective RCs, if you have acquired adapter
separately or later.
From Ver. 3.00 B will be supported:
Mixer with Reedcontact or microsensor,
Mixer with of impulse control (for example
PIONEER) is Ver. 3.00 C required.
The version number of your Remote Control Unit
will be shown during start-up / Program start of
BPM Studio. (By pressing CTRL key, the dialog
box stays visible until the key will be released
again).
[38] Serial cable socket (reverse side)
Connect plug (9-pin, Sub-D) of Remote Control
Unit through serial cable to your PC. The maxi-
mal cable's length is 15 m, however we do not
recommend to use more than 10 m.
[39] Power supply socket (reverse side)
Connect delivered power supply cable (9 V, at
least 500 mA).
[52] Fader start cable socket (reverse side)
Connect to this plug (9-pin, Sub-D) an Fader start
cable which is optional available as accessory
by ALCATech. Please read instructions of 'Fader
start' on the following pages of the manual before
using it the first time.
(BPM Studio Pro/HW from Ver. 3.00 B)
In the program options, you can choose the
following different operation modes:
Fader Start (Program options / Remote
Control Unit)
If this checkbox is active, then Player starts when
the control of the external mixer will be put on.
Fader Stop (Program options / Remote
Control Unit)
If this checkbox is active, then Player stops when
the control of the external mixer will be put off.
RC V3 Description
