Front Panel Display

1.
PM
: Appears in the afternoon
with the clock display.
(Nothing appears in the
morning.)
2.
DTV
: Appears when the channel
is in DTV mode.
3. Title / track / file and chapter mark
: Appears when indicating a
title / track / file number.
: Appears when indicating a
chapter number.
Display Message
14 EN EN
FUNCTIONAL OVERVIEW
2
DTV BS CS
PM
1
4. Current status of the unit
: Appears when playback is
paused.
: Appears when playing back
an HDD or disc.
: Appears when the timer
programming or OTR has
been set and is proceeding.
Entire Display:
Flashes when timer
programming was not executed
because of some error.
: Appears during recording
process.
Entire Display:
Flashes when a recording
pauses.
: Appears when a disc is in
this unit.
DB
: Appears during dubbing.
HDD
: Appears when the unit is in
HDD mode.
DVD
: Appears when the unit is in
DVD mode.
Appears when the disc tray is
opening.
Appears when the disc tray is
closing.
Appears when a disc is loaded
on the disc tray.
Appears when data is being
recorded on a disc.
Appears when the PBC function
is activated. (Video CD playback
only. Refer to page 68.)
3
DR CD
VCR
DB HDD
DVD
5
5. Displays the following
4
• Elapsed playback time
• Current title / chapter / track /file
number
• Recording time / remaining time
• Clock
• Channel number
• Remaining time for one-touch
timer recording
• Selected HDMI output
Appears when HDMI output
(480p) is selected.
Appears when HDMI output
(720p) is selected.
Appears when HDMI output
(1080i) is selected.
Appears when HDMI output
(1080p) is selected.
