JUNTTAN PM 20L Operator's Manual page 96

JUNTTAN
JUNTTAN ROUTINE SERVICE CHART PM 20
DAILY OR EVERY 8 HOURS
Object:
Engine crankcase oil
Coolant
Hydraulic tank oil
Machine
Lifting devices
Cross joint
Indicators and gauges
Emergency stops
AFTER EACH 40 HOURS/WEEKLY
1. Grease the slewing ring ball races (lubrication pipes with grease nipples are in the
hydraulic compartment).
2. Grease the nipples in the upper and lower slide.
3. Grease the nipples in the upper and lower swivels of the inclination cylinders.
4. Grease the nipples in the stabilizers (optional).
5. Grease the nipples of the leader guides.
6. Apply grease with a brush to the bottom of the horizontal slide.
7. Grease the nipples of the leader lift device .
8. Check the bearings of the sheaves (the bearings are lubricated for life).
9. Check the condition of the ropes and lubricate them with brush (see standard ISO
4309).
10. Grease the slewing ring pinion gear.
11. Check the play of the track frame slide beams.
12. Check the bearings of the winches top limit in the cathead.
13. Check the level of the electrolyte in the batteries, clean batteries and terminals.
14. Check the track drive transmission oil level.
15. Check the swing drive transmission oil level.
16. Check the inclinometer calibration.
MONTHLY
17. Grease the nipples in the cathead.
96
Routine service section
Measure:
Check oil level
Check coolant level
Check oil level
Walk-Around inspection
Walk-Around inspection
Grease and check
Test
Test
