JUNTTAN
6.8

TRANSPORTING AND STORING THE MACHINE

6.8.1

DRIVING ONTO A TRAILER

Check that the trailer is on level and stable ground. Use ramps to drive the machine onto
the trailer. Do not exceed the maximum climbing angle (15º) when using ramps. While
you are on the ramps you may have to lift the leader slightly so that the cathead does not
touch ground. Once you have the machine on the trailer, centre it in relation to the width
of the trailer and drive it as far to the front end of the trailer as you can, so that it will
clear the lorry and any gooseneck on the trailer. Always lock the slewing mechanism for
transport.
6.8.2

DRIVING OFF A TRAILER

Position the trailer on level and stable ground with sufficient space to swing the
machine around with the leader lowered. Disengage the slewing mechanism lock with
the switch on the right console. Do not exceed the maximum climbing angle (15º) when
using ramps.
While you drive the machine off the trailer, you may have to lift and lower the leader
slightly at times in order to clear the lorry, any gooseneck on the trailer, and the ground.
Always use ramps when you drive the machine off a trailer.
86
Daily operation section
