JUNTTAN
4.

GENERAL SECTION

4.1

MAJOR COMPONENTS

The construction of the machine is a rotating machinery deck with leader on crawler-
mounted undercarriage. The piling leader consists of a leader, basic leader and optional
leader extension. The bottom of the leader is connected with the cross joint to the
horizontal slide. These allow vertical and horizontal positioning of the leader. The
lateral inclination cylinders and the forward/backward inclination cylinder control the
inclination of the leader through the upper slide. The leader slides axially in relation to
the basic leader. There are two winches at the rear of the machinery deck. The ropes run
through sheaves in the upper slide and cathead to the front of the leader. The leader lift
device lifts and lowers the leader from and to the transport position.
4.2

LOCATION OF THE SERIAL NUMBERS

For the location of the product identification number (PIN) see Figure 4.
For the location of the engine serial number see Figure 5.
For the location of the track drive serial numbers see Figure 6.
For the location of the swing drive serial number see Figure 7.
