7.5

ENGINE AIR CLEANER

The air cleaner is situated in the engine compartment on top of the engine. The paper
cartridge must be changed when the air cleaner indicator in the cab lights up or at least
once a year. For further information see attached engine operation and maintenance
manual.
7.6

FILLING AND DRAINING OF THE FUEL TANK

You can fill the fuel tank either through the refuelling pipe (1) or with the electric
refuelling pump (2). Start the pump with the switch (3). The fuel is pumped to the tank
through the hose (4). You can see the fuel level from the gauge in the cab and from the
level glass (5). Stop the pump when the tank becomes nearly full. When you fill the
tank, leave room for thermal expansion.
To drain the fuel tank, open the valve which is placed near slewing ring. Do not spill
fuel on the ground. Drain the tank at least twice a year to clear all dirt and water from
the fuel tank. Clean the fuel tank through the manholes. When you close the manholes
make sure that the covers sit tightly, otherwise you provide access for water and dirt
into the fuel tank. The indicator for the fuel meter is in the manhole.
1
5
118
4
Routine service section
3
2
