17.5mV. This is used to increase the range of the domain frequency in extreme
overclocking conditions. Enter 0 to use the manufacturer default value.
GT PLL Voltage Offset
Use this feature to set the PLL Voltage Offset value from 0-15 with each unit at
17.5mV. This is used to increase the range of the domain frequency in extreme
overclocking conditions. Enter 0 to use the manufacturer default value.
Ring PLL Voltage Offset
Use this feature to set the PLL Voltage Offset value from 0-15 with each unit at
17.5mV. This is used to increase the range of the domain frequency in extreme
overclocking conditions. Enter 0 to use the manufacturer default value.
System Agent PLL Voltage Offset
Use this feature to set the PLL Voltage Offset value from 0-15 with each unit at
17.5mV. This is used to increase the range of the domain frequency in extreme
overclocking conditions. Enter 0 to use the manufacturer default value.
Atom Core PLL Voltage Offset
Use this feature to set the PLL Voltage Offset value from 0-15 with each unit at
17.5mV. This is used to increase the range of the domain frequency in extreme
overclocking conditions. Enter 0 to use the manufacturer default value.
Memory Controller PLL Voltage Offset
Use this feature to set the PLL Voltage Offset value from 0-15 with each unit at
17.5mV. This is used to increase the range of the domain frequency in extreme
overclocking conditions. Enter 0 to use the manufacturer default value.
AVX Configuration
AVX2 Voltage Guardband Scale Factor
AVX2 Voltage Guardband Scale Factor controls the voltage guardband applied to
AVX2 workloads. A value > 1.00 will increase the voltage guardband, and < 1.00
will decrease the voltage guardband.
FIVR Configuration
Core Voltage Mode
Selects between Adaptive and Override Voltage modes. In Override Mode, the volt-
age selected will be applied over all operating frequencies.In Adaptive mode, the
voltage is interpolated only in turbo mode.
