Z690 Phantom Gaming 4/D5
ODT WR (B2)
Configure the memory on die termination resistors' WR for channel B2.
ODT NOM Rd (A1)
Configure the memory on die termination resistors' NOM Rd for channel A1.
ODT NOM Rd (A2)
Configure the memory on die termination resistors' NOM Rd for channel A2.
ODT NOM Rd (B1)
Configure the memory on die termination resistors' NOM Rd for channel B1.
ODT NOM Rd (B2)
Configure the memory on die termination resistors' NOM Rd for channel B2.
ODT NOM Wr (A1)
Configure the memory on die termination resistors' NOM Wr for channel A1.
ODT NOM Wr (A2)
Configure the memory on die termination resistors' NOM Wr for channel A2.
ODT NOM Wr (B1)
Configure the memory on die termination resistors' NOM Wr for channel B1.
ODT NOM Wr (B2)
Configure the memory on die termination resistors' NOM Wr for channel B2.
ODT PARK (A1)
Configure the memory on die termination resistors' PARK for channel A1.
ODT PARK (A2)
Configure the memory on die termination resistors' PARK for channel A2.
ODT PARK (B1)
Configure the memory on die termination resistors' PARK for channel B1.
ODT PARK (B2)
Configure the memory on die termination resistors' PARK for channel B2.
ODT PARK DQS (A1)
Configure the memory on die termination resistors' PARK DQS for channel A1.
69
