Z690 Phantom Gaming 4/D5
tRDWR_dr
Configure between module write to read delay.
tRDWR_dd
Configure between module write to read delay.
tWRRD_sg
Configure between module write to read delay.
tWRRD_dg
Configure between module write to read delay.
tWRRD_dr
Configure between module write to read delay.
tWRRD_dd
Configure between module write to read delay.
tWRWR_sg
Configure between module write to write delay.
tWRWR_dg
Configure between module write to write delay.
tWRWR_dr
Configure between module write to write delay.
tWRWR_dd
Configure between module write to write delay.
Round Trip Timing
Round Trip Timing Optimization
Auto is enabled in general case.
Round Trip Level
Configure round trip level.
Initial RTL IO Delay Offset
Configure round trip latency IO delay initial offset.
67
