Z690 Phantom Gaming 4/D5
CPU Core Current Limit
Configure the current limit of the CPU core. A lower limit can protect the CPU and
save power, while a higher limit may improve performance.
GT Unlimited Current Limit
To unlock voltage regulator current limit completely, you can set this option to
Enabled.
GT Current Limit
Configure the current limit of the GT slice. A lower limit can protect the CPU and
save power, while a higher limit may improve performance.
DRAM Configuration
Memory Information
Allows users to browse the serial presence detect (SPD) and Intel extreme memory profile
(XMP) for DDR5 modules.
DRAM Timing Configuration
DRAM Reference Clock
Select Auto for optimized settings.
DRAM Frequency
If [Auto] is selected, the motherboard will detect the memory module(s) inserted
and assign the appropriate frequency automatically.
DRAM Gear Mode
Gear2 mode doubled the ratio in memory controller, and it is good for high
frequency.
BCLK Frequency
Configure the BCLK Frequency.
Primary Timing
CAS# Latency (tCL)
The time between sending a column address to the memory and the beginning of the data
in response.
RAS# to CAS# Delay and Row Precharge (tRCDtRP)
RAS# to CAS# Delay : The number of clock cycles required between the opening of a row
63
