Troubleshooting 6 Blinks Failure (All VT60 and ZT60 Models)
Applies to
Models
TC-P55VT60
TC-P60VT60
TC-P65VT60
TC-P60ZT60
TC-P65ZT60
Verify that all the cables on the SC and SS boards are properly seated. Also check the ribbon cables and connectors on the A and C
boards. Unplug the TV and disconnect connector SC20 on the SC board. Plug in the TV
automatically after the TV is plugged in as expected, then press the power switch.
Replace the A
board
Start Here
6 Times
Is the power
LED blinking 6
or 8 times?
Blink
List of boards likely to cause this symptom.
Code
No.1
No.2
6 Blinks
SC
A
Note:
If the power LED does not turn on
8 Times
No.3
No.4
Replace the SC
board
