Re-installation or Replacing the Battery

If the phone or GPRS connection function is already activated,
deactivate it first and run the next step; otherwise abnormal disconnection
will occur.
1. Press the fixing lock button on the rear side of the Pocket PC and remove
the back cover.
2. Slide the main battery lock down to open the main battery lock. Now you
can easily remove the battery.
3. Replace the main battery and lock it properly. When you remove the main
battery, the system operation will be powered temporarily by the backup
battery.
4. Slide the back cover into the groove until you hear a click to indicate that
the back cover lock is locked properly.
Follow the directions in the figure to install or remove the battery
properly.
Back cover lock.
Main battery lock. Slide down to unlock and slide up to lock.
2-8
Unlock
Lock
