The UART configuration Bitfiled key is a presentation key. Set this to
UART: Stop Bits PS Key to
UART: Parity Bit PS Key to
UART: Hardware Flow Control? PS Key to
UART: RTS Asserted? PS Key to
UART: Enable BCSP-specific hardware PS Key to
5.2.4

PSTools User Interface

Once the transport interface has been selected, PSTools opens with a user interface window, as shown in Figure
5.4. The function of each button or area is described as follows:
: This window lists all of the PS Keys that are available at the current access level.
Persistent Store Key List
: This button programs the values in the data area into the currently selected PS Key.
Set
: This button removes a PS Key from the Persistent Store. If required, the stack will create the key using a
Delete
default value the next time the stack reboots. Otherwise, the key will continue to be reported in the status area as
"Not present".
: Clicking this button reads the value of the selected PS Key into the data area. A read is also performed
Read
every time a new PS Key is selected.
: This button brings up the transport interface selection window, allowing you to reconnect after
Reconnect
resetting or if the transport was disrupted for any reason.
: This button resets the BlueCore device. Any changes to the PS Keys will take effect only after the
Reset BC
device is reset and the stack reboots.
: This shuts down PSTools.
Close
: This button brings up a description of the currently selected PS Key.
Describe
: This area provides details such as PS Key number and Friendly Name or Programmer ID plus the
Status Area
status of the transport interface. If this shows "Entry is not present" for a key that should always be present (such
as the Bluetooth Address) then there are probably problems with the transport interface.
: This area shows the data that is stored in the selected PS Key and allows you to edit it.
Data Area
: This button allows you to save PS Keys as you choose. PS Keys can be retrieved through the
Dump
function. See Figure 5.4.
: This button opens PS Keys that were saved through
Merge
: This item allows you to change the default PS Key setting to one of your own preference (e.g., baud
Edit Raw
rate). provides more information about each PS Key setting. See Figure 5.5.
Describe
The menu bar offers various other features including a low level PS Key editor, the ability to alter the PS Key List
to display Friendly Names or Programmer IDs and to sort using Name or Number. It also duplicates may of the
button functions.
Important Note:
Changes to a PS Key will not take effect until BlueCore resets and the stack reboots.
bc01-an-100Pd
One stop bit
No parity
Enabled
True
© Copyright Cambridge Silicon Radio Limited 2001-2004
This material is subject to CSR's non-disclosure agreement.
BlueCore Utilities in BlueSuite
configure to the following keys:
168
False
. See Figure 5.4.
Dump
Merge
Page 17 of 33
