CSR BlueCore Casira User Manual page 16

To change to BCSP:
1. Change the Host Interface.
Select the Host Interface PS Key (505 PSKEY_HOST_INTERFACE).
Set to UART link running BCSP
Click on to update the Persistent Store.
Set
2. Configure the UART interface.
Select the PSKEY UART configuration bitfield (517 PSKEY_UART_CONFIG).
Set this value to
Click on to update the Persistent Store.
Set
3. Set baud rate.
Select the UART baud rate PS Key (516 PSKEY_UART_BAUD_RATE).
Set to the required baud rate (e.g., 115.2 kbaud).
Click on to update the Persistent Store.
Set
4. Reset BlueCore.
This configures the BlueCore module to use BCSP over the UART.
The UART configuration Bitfiled key is a presentation key. Setting this to
UART: Stop Bits PS Key to
UART: Parity Bit PS Key to
UART: Hardware Flow Control? PS Key to
UART: RTS Asserted? PS Key to
UART: Enable BCSP-specific hardware PS Key to
To change to H4:
1. Change the Host Interface.
Select the Host Interface PS Key (505 PSKEY_HOST_INTERFACE).
Set to UART link running H4
Click on to update the Persistent Store.
Set
2. Configure the UART interface.
Select the PSKEY UART configuration bitfield (517 PSKEY_UART_CONFIG).
Set this value to
Click on to update the Persistent Store.
Set
3. Set baud rate.
Select the UART baud rate PS Key (516 PSKEY_UART_BAUD_RATE).
Set to the required baud rate (e.g., 115.2 kbaud).
Click on to update the Persistent Store.
Set
4. Reset BlueCore.
This configures the BlueCore module to use H4 over the UART.
bc01-an-100Pd
using the pull-down menu.
6 .
One stop bit
Even Parity
Disabled
False
using the pull-down menu.
.
168
© Copyright Cambridge Silicon Radio Limited 2001-2004
This material is subject to CSR's non-disclosure agreement.
BlueCore Utilities in BlueSuite
6 configures the following keys:
Enabled
Page 16 of 33
