Descriptive Data; Main Rotor; Tail Rotor; Transmission - Guimbal CABRI G2 Flight Manual

Hélicoptères Guimbal
CABRI G2

Descriptive data

Main rotor

Type ............................................................. Articulated, soft-in-plane
Number of blades ................................................................................. 3
Diameter ...................................................................................... 7,20 m
Nominal rotor speed ................................................................ 530 RPM
Blade chord ............................................................................... 180 mm

Tail rotor

Type ....................................................................................... Shrouded
Number of blades ................................................................................. 7
Diameter .................................................................................... 600 mm
Nominal rotor speed .............................................................. 5148 RPM
Blade chord ................................................................................. 42 mm

Transmission

Primary transmission ........................................................................Belt
Main rotor gearbox ..................................................... Spiral bevel gear
Tail rotor gearbox ....................................................... Spiral bevel gear
Issue 03
Original issue
Approved under DOA EASA.21J.211
SECTION 1
GENERAL
(23.6 feet)
(7.1 in)
(23.6 in)
(1.6 in)
0.855/1 reducing ratio
11/47 reducing ratio
25/11 increasing ratio
1-3
