Craftsman CMXGCAQ108493 Operator's Manual page 27

ENGINE ASSEMBLY
Item # Part # Description
1 101138 Frame Plate
2 101151 Debris Guard
3 101148 Belt Guide
4 100125 Hex Bolt, M8 x 1.25 x 20mm, G8.8
5 101300 Hex Bolt, 5/16-18 x 3", G5
6 100126 Hex Bolt, M8 x 1.25 x 30mm, G8.8
7 101140 Engine Belt Pulley
8 101146 Idler Stand Off
9 101136 Engine, Kohler XT6.5, 49ST
10 101145 Spring
11 101150 Safety Guard
12 101050 Cutting Head Assembly
13 101049 Nose Cover
14 100128 Hex Nut, Nylock, M8 x 1.25, G8.8
15 101494 Hex Nut, Nylock, M6 x 1.0, G8.8
16 101491 Hex Bolt, 3/8-16 x 1.5, G5
17 101492 Hex Bolt, M6 x 1.0 x 14, G8.8 1
18 101493 Hex Bolt, M8 x 1.25 x 20, G8.8
19 101536 Hex Bolt, M6 x 1.0 x 20, G8.8
20 100611 Lock Washer, 3/8
21 100127 Lock Washer, M8
22 100202 Lock Washer, M6
23 100579 Hex Nut, M8 x 1.25
24 100198 Hex Nut, M6 x 1.0, G8.8
25 100077 Flat Washer, 1/2"
26 100130 Flat Washer, M8
27 107456 V-Belt, 3L X 44"
28 101137 Tension Pulley Bracket
29 101227 Engine Belt Guide
30 101225 DHT Decal
31 101052 Danger Decal
32 101054 Safety Decal
33 101144 Idler Pulley Flat
34 101143 Idler Pulley V
35 101810 Pulley Bottom Bracket
36 101147 Spacer, Idler Pulley
37 108747 Debris Guard Bar
27
Qty.
1
1
1
4
1
1
1
1
1
1
1
1
1
1
3
3
4
4
1
4
9
4
9
4
2
2
1
1
1
1
1
1
1
1
1
2
1
