IDU ES Applications

IDU ES may be used to provide single-hop connections or used as a radio backbone in
multiple-hop star or ring networks.
Refer to:
• Basic Network Applications on page 2-23.
• Ring Applications on page 2-25
Basic Network Applications
Simple Link
Figure 2-11 illustrates basic link operation where the IDU ES directly supports up to 4
hosts, which may all be on a common LAN, or prioritized in VLAN mode on up to four
LANs over two independent link transport channels, C1 and C2.
260-668066-001 Rev 024 February 2009
Description
IDU Status LED provides indications of:
Off IDU power off
Green Normal operation
Orange flashing Configuration not supported or software/
hardware incompatible, or diagnostic mode
selected, such as tributary loopbacks.
Red Critical alarm (traffic affecting)
RJ-45 connector provides a port for Ethernet network
management access. Unless DHCP has been configured, Portal
login requires entry of a LAN compatible IP address on your PC.
Port may also be used to provide NMS connectivity to
co-located Harris Stratex or third party radios.
The green connection-status LED is on for a valid Ethernet
connection. Off indicates no connection or an invalid
connection.
The orange activity LED flashes to indicate Ethernet traffic on
the port. The LED does not flash (is solid on) when there is no
traffic activity. (Activity LED is off when the connection status
LED is off).
RJ-45 connector assembly for 10/100Base-T Ethernet traffic
connection.
Port connection-status and activity LED indications are as for
the NMS port.
RJ-45 connector assemblies for wayside tributary connections;
one RJ-45 port per E1/DS1. E1 termination is set for
unbalanced or balanced in Portal. DS1 is 100 ohms balanced
with options for AMI or B8ZS, and trib cable length. Cable
options provide extension to BNC connectors for unbalanced,
or to RJ-45 plugs or unterminated wires for balanced.
