Chapter 2. Eclipse Terminals
• E1/DS1 traffic is terminated on a DAC 16x or DAC 4x.
• Auxiliary data traffic and/or alarm I/O actions are terminated on an AUX.
Table 2-9.
Ethernet
Assignment
10 Mbps
20 Mbps
20 Mbps
32 Mbps
40 Mbps
40 Mbps
80 Mbps
106 Mbps
150 Mbps
150 Mbps
190 Mbps
196 Mbps
Table 2-10.
Ethernet
Assignment
43 Mbps
49 Mbps
49 Mbps
108 Mbps
108 Mbps
154 Mbps
154 Mbps
154 Mbps
Ethernet Module
The Ethernet module incorporates an intelligent layer 2 (L2) switch, to provide the
switching, prioritization and queuing functions between ports P1 to P4 and transport
channels, C1 and C2. It supports address learning for efficient management of Ethernet
traffic in multi-host situations, and advanced L3 and L2 settings for traffic
prioritization.
A gate array supports channel assignment and mux/demux to the digital baseband.
The MAC address register supports 2048 entries.
Vol. II-2-16
IDU ES Compatibility with RAC 30 and RAC 3X: ETSI
BW MHz Modulation
7 MHz QPSK
7 MHz 16QAM
14 MHz QPSK
7 MHz 64QAM
28 MHz QPSK
14 MHz 16QAM
28 MHz 16QAM
28 MHz 32QAM
56 MHz 16QAM
28 MHz 128QAM
28 MHz 256QAM
56 MHz 64QAM
IDU ES Compatibility with RAC 30 and RAC 3X: ANSI
BW Modulation
10 MHz 64 QAM
20 MHz 16 QAM
40 MHz QPSK
30 MHz 16 QAM
40 MHz 32 QAM
30 MHz 128 QAM
40 MHz 32 QAM
50 MHz 16 QAM
IDU ES RAC30v3
RAC 30A &
RAC30v2+
X X
X X
X X
X X
(RAC 30v3 only)
X X
X X
X X
X X
X N/A
X X
X N/A
X N/A
IDU ES RAC 30v3
RAC 30A
X X
X X
X N/A
X X
X N/A
X X
X N/A
X N/A
