Harris Stratex Eclipse 4.6 User Manual page 81

Figure 2-6.
Table 2-8.
Ethernet
BW, Mbps
43
49
49
94
108
108
108
154
154
154
196
196
1. FCC frequency efficiency restrictions mean these options are not available for use in the 6
and 11 GHz Common Carrier bands.
IDU ES Compatibility
IDU ES can be over-air interfaced to an INU/INUe fitted with a RAC 30v3, RAC 30A
(non-adaptive modulation) or RAC 3X. For ETSI bands it also applies to RAC 30v2+.
IDU ES can also be over-air interfaced to an IDU GE 20x. Refer to IDU GE 20x
Compatibility on page 2-31.
Table 2-9 indicates current INU compatibility for ETSI rates; Table 2-10 indicates
ANSI rates.
At the INU/INUe:
• Ethernet traffic is terminated on a DAC ES or DAC GE.
260-668066-001 Rev 024 February 2009
Connect ES Options with ODU 300hp or ODU 300ep: ANSI
Connect ES Options with ODU 300hp or ODU 300ep: ANSI
Channel Modulation
BW, MHz
10 64 QAM
20 16 QAM
40 QPSK
20 64 QAM
20 128 QAM
30 32 QAM
40 16 QAM
30 128 QAM
40 32 QAM
50 16 QAM
40 128 QAM
50 64 QAM
Eclipse User Manual
License Connect ES Option
Base Connect ES 50
Base Connect ES 50
Base Connect ES 50
Upgrade 1 Connect ES 100
Upgrade 1 Connect ES 100
Upgrade 1 Connect ES 100
Upgrade 1 Connect ES 100
Upgrade 2 Connect ES 150
Upgrade 2 Connect ES 150
Upgrade 2 Connect ES 150
Upgrade 3 Connect ES 200
Upgrade 3 Connect ES 200
1
1
1
1
Vol. II-2-15
