Harris Stratex Eclipse 4.6 User Manual page 80

Chapter 2. Eclipse Terminals
Figure 2-5.
Table 2-7.
Ethernet
BW, Mbps
1
10
20
20
32
40
40
55
64
82
106
150
150
190
196
1. A 10 Mbps, 3.5 MHz, 16 QAM option is planned for later release. Contact
Harris Stratex Networks or your supplier for details.
Vol. II-2-14
Connect ES Options with ODU 300hp or ODU 300ep: ETSI
Connect ES Options with ODU 300hp or ODU 300ep: ETSI
Channel Modulation
BW, MHz
7 QPSK
7 16 QAM
14 QPSK
7 64QAM
28 QPSK
14 16QAM
14 32QAM
28 16 QAM
28 16 QAM
28 32 QAM
28 128 QAM
56 16 QAM
28 256QAM
56 64 QAM
License Connect ES Option
Base Connect ES 50
Base Connect ES 50
Base Connect ES 50
Base Connect ES 50
Base Connect ES 50
Base Connect ES 50
Base Connect ES 50
Base Connect ES 50
Upgrade 1 Connect ES 100
Upgrade 1 Connect ES 100
Upgrade 2 Connect ES 150
Upgrade 2 Connect ES 150
Upgrade 3 Connect ES 200
Upgrade 3 Connect ES 200
Harris Stratex Networks
