Ethernet capacity (bandwidth) is assigned in 2.048 Mbps or 1.544 Mbps
steps to align with the capacity needed for E1 or DS1 waysides. Eclipse
incorporates a universal modem design that does not distinguish
between the type of data to be transported, Ethernet or TDM; data is
simply mapped into byte-wide frames to provide a particularly efficient
and flexible wireless transport mechanism, with the result that when
configured for Ethernet data, or Ethernet and TDM data, the full
configured, native capacity is available for user throughput.
Figure 2-4.
Table 2-6.
Ethernet
BW,
Mbps
20
20
40
40
64
82
260-668066-001 Rev 024 February 2009
Connect ES Options with ODU 300sp: ETSI
Connect ES Options with ODU 300sp: ETSI
Channe Modulatio
l BW, n
MHz
7 16 QAM
14 QPSK
14 16QAM
28 QPSK
28 16 QAM
28 16 QAM
License Connect
ES Option
Base Connect ES
40
Base Connect ES
40
Base Connect ES
40
Base Connect ES
40
Upgrade Connect ES
80
Upgrade Connect ES
80
