No Item/Label
17 IP Reset recessed
switch
Ethernet IDUs
This section introduces the IDU ES and IDU GE 20x. Both IDUs may be ordered
separately or included in an Eclipse 'Connect' link package, where a package includes
two IDUs with companion ODUs. Connect options are designed to to provide an
uncomplicated and cost effective product solution for link installations.
Refer to:
• IDU ES
• IDU GE 20x
IDU ES
IDU ES supports Fast Ethernet connections to 200 Mbps with up to 8xE1/DS1 wayside
circuits. Depending on the ODU and required capacity, over-air channel bandwidths
are selected using modulation options from QPSK to 256 QAM.
IDU ES includes a Layer 2 switch to support four customer 10/100base-T ports, two
over-air transport channels and comprehensive QoS options.
Base capacity licences apply, with access to the higher capacities provided by an
additional software-keyed license.
An IDU ES can be over-air interfaced to an Eclipse Node or IDU GE 20x.
Refer to:
• Connect ES Link Package on page 2-12
• Connect ES Capacity and Bandwidth Options on page 2-12
• IDU ES Compatibility on page 2-15
• Ethernet Module on page 2-16
• Wayside Traffic Module on page 2-21
• Auxiliary Data and Alarm I/O Module on page 2-21
• IDU ES Layout on page 2-22
• IDU ES Applications on page 2-23
For more information, refer to:
• Outdoor Units on page 4-1.
260-668066-001 Rev 024 February 2009
Description
IP Reset enables:
• A temporary DHCP Ethernet connection. Used where the IDU
has not been configured (no IP address set).
• IDU reset; the IDU is reset to a factory default configuration.
For information on the operation of this switch refer to Factory
Reset on page 2-59.
Eclipse User Manual
Vol. II-2-11
