Chapter 2. Eclipse Terminals
This chapter describes features and capabilities of Eclipse Terminals. Refer to:
• PDH and SDH IDUs on page 2-1
• Ethernet IDUs on page 2-11
• IDU Protection on page 2-44
• Platform Layout and Interoperation Data on page 2-53
• Configuration and Diagnostics on page 2-57
For information on Eclipse ODUs refer to Chapter 4.

PDH and SDH IDUs

This section introduces traffic and auxiliary interfaces and functions for:
Table 2-1.
IDU
IDU 300 8x
IDU 300 20x
IDU 300 20xV2
IDUsp 4x
IDUsp16x
IDU 155o
1. IDU 300 20xV2 operation for capacities greater than 20xE1 or
16xDS1 is capacity licensed. Two IDUs are used, linked by an
expansion cable.
Refer to:
• Capacity and Bandwidth Options on page 2-2
• Traffic and Auxiliary Interfaces on page 2-4
• Front Panel Layout on page 2-7
IDUsp and IDU 155o may be individually ordered, or ordered as a
'Connect' link comprising two terminals, each with one IDU, and one ODU
300 outdoor unit to provide a basic link package. Direct-mount antenna
and ODU cable options are separately ordered.
260-668066-001 Rev 024 February 2009
300 Series IDUs
Maximum Capacity
8xE1/DS1
20xE1 or 16xDS1
20xE1 or 16 xDS1
40xE1 or 32xDS1
4xE1
16xE1
STM1/OC3
1
Vol. II-2-1
