Chapter 1. System Overview
This section overviews the features and capabilities of Eclipse. It describes:
• Eclipse Platforms on page 1-1
• Eclipse Configuration and Management on page 1-17
• Antennas on page 1-17
• Power Supply on page 1-18
• Platform Layout and Interoperation Data on page 1-18

Eclipse Platforms

Eclipse is available on two platform types, Terminal and Node. Both employ a
split-mount architecture with a rack-mounted indoor unit and direct-mounted ODUs
connected by a single coaxial cable. Refer to:
• Eclipse Terminal on page 1-1
• Eclipse Node on page 1-6
• Eclipse ODUs on page 1-14
Eclipse Terminal
Eclipse Terminals are single-link radios, comprising an IDU and ODU. Multiple IDUs
are in the IDU 300 product group. Three ODUs are available for these IDUS.
Terminals may be operated as single links, or networked where IDUs are back-to-back
connected via their tributary ports at intermediate sites.
Most Terminals can be paired for protected link operation.
Terminals may also be over-air interfaced to like Terminals of higher or lower ultimate
capacity and, with the exception of the IDUsp, to Eclipse Node.
Refer to:
• 300 Series Indoor Units on page 1-2
• Eclipse Node on page 1-6
260-668066-001 Rev 024 February 2009 Vol. II-1-1
