BMW 3-series convertible Complete Vehicle Workbook page 91

Workshop Exercise - RHT Service
After the removal of the rear module, proceed with removal of the
roof module.
Be sure plastic cover on hydraulic unit has been removed.
Unclip all cable holders for electrical and hydraulic lines.
(Remove CD Changer if equipped)
Make sure all necessary electrical connectors have been
unplugged.
Install special tool to protect rollover protection system.
List the special tool # shown in the above illustration:
Release all required fasteners in preparation for removal of the
roof module. Replace bushing during re-assembly.
Secure metallic object (washer etc.) on the luggage compartment
Hall sensor to simulate closed luggage compartment divider.
Prepare special tool (1) by fully collapsing before installation.
E93 Complete Vehicle Workbook
91
