BMW 3-series convertible Complete Vehicle Workbook page 82

Hard Top System Schematic
82
E93 Complete Vehicle Workbook
Index Explanation
1
Car Access System (CAS 3)
2
"Cowl panel reached" micro switch
3
"Catch hook locked" micro switch
4
"Catch hook unlocked" micro switch
Operating button for retractable hard
5
6
Junction Box (electronics)
7
Convertible Top Module (CTM)
8
"Open roof shells" Hall sensor
9
"Close roof shells" Hall sensor
10
"Closure open" Hall Sensor
11
"Right closure closed" microswitch
Index
"Rear module open"
12
"Rear module almost closed"
13
"Roof package stowed"
14
"Rear module closed"
15
"Roof package extended"
16
top
17
Hydraulic unit (pump,motor,valves)
"Luggage compartment divider"
18
19
20
"Left closure" microswitch
Electric motor for fastener on cowl
21
panel and interlocking of roof shells
Explanation
Hall sensor
Hall sensor
Hall sensor
Hall sensor
Hall sensor
Hall sensor
Diversity aerial
