BMW 3-series convertible Complete Vehicle Workbook page 78

Workshop Exercise - Sensors and Switches
Complete the chart below by filling in the required information on the status of the RHT.
The status of the top is shown at the right. Place the top in this position and use the
diagnostic equipment to access the required information (i.e. status requests etc).
Micro-switch/Hall Sensor description
"Cowl panel reached"
"Catch hook (cowl panel) locked"
"Catch hook (cowl panel) unlocked"
"Roof panels (shells) partially closed"
"Roof panels (shells) partially opened"
"Right closure (coupling) open"
"Right closure (coupling) closed"
"Rear module closed"
"Roof package stowed"
"Rear module open"
"Rear module almost closed"
"Luggage compartment divider"
"Roof package extended"
"Left closure (coupling) closed"
78
E93 Complete Vehicle Workbook
Type ETM/Component #
Microswitch
Microswitch
Microswitch
Hall Sensor
Hall Sensor
Hall Sensor
Microswitch
Hall Sensor
Hall Sensor
Hall Sensor
Hall Sensor
Hall Sensor
Hall Sensor
Microswitch
Status in Diagnosis (No/Yes) Component location
