BMW 3-series convertible Complete Vehicle Workbook page 57

Workshop Exercise- Sequence of operation
Using the actual vehicle as a guide, operate the top through the opening and closing operations. Note the sequence and
complete the exercise below by numbering the illustrations below in the correct order starting with the top open.
Operate the RHT using the center console switch and note the status of the LED's in the switch. Interrupt the RHT during opera-
tion to see how the LED's are affected.
Next, attempt to operate the RHT with one or more of the preconditions in the incorrect state (i.e. luggage compartment divider up
or trunk open etc.) The note the CC messages and icons which appear.
What type of sensor/switch senses the position of the luggage compartment divider?
If the vehicle does not have CCC, how is the driver warned of improper operation?
E93 Complete Vehicle Workbook
57
