Schematic for Antenna Systems
34
E93 Complete Vehicle Workbook
Index
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Explanation
Car Access System
Remote control receiver in interior rear view mirror
CCC
Junction box
Rejector circuit, negative
FM3 antenna with amplifier in right hand shoulder trim
Comfort Access
Convertible Top Module
FM2 antenna in bumper
FM4 antenna in bumper
FM antenna diversity module
AM/FM1 antenna with amplifier in left hand shoulder trim
AM/FM antenna amplifier in rear window
Rejector circuit, positive
