Workshop Exercise - Bus System Changes
Using the bus chart and classroom posters for comparison,
answer the following questions.
What has changed on the LIN-bus? And Why?
Has anything changed in the diagnostic connection?
What three modules are connected to the K-bus?
What new modules are on the MOST bus?
What has changed regarding the wiring of the SINE and FZD?
Which bus connects the microwave sensors to the SINE?
