3RD. FREE INSPECTION COUPON
JOB MARK: √
: Checked OK, A: Adjust, C: Clean, R: Replace or Change, L: Lubricate, T: Tighten,
O:Rotate, I: Inspect and correct or replace If necessary.
1. ENGINE
1. Engine Coolant (Level, Leakage)
2. Cooling System hoses & connections
(Leakage, Damage)
3. Engine oil & oil filter (Replace)
4. Cylinder head bolts (Tight)
5. Engine Mounting and Manifold fixing
(Noise, Leakage, Damage etc)
2. FUEL
1. Air cleaner / Cyclon (Clean) (Petrol)
2. Fuel Filter, Fuel tank cap, Fuel lines and
connections (Leakage)
3. Fuel filter & water draining (Diesel)
3. CLUTCH AND TRANSMISSION
1. Clutch pedal (Play) (Petrol)
2. Clutch slipping (Dragging, Damage)
3. Transmission Oil (Level Leakage)
4. Gear Shifter Cables (Operation)
5. Drive shaft boots (Damage)
6. Clutch Fluid (Level, Leakage) (Diesel)
4. BRAKE
1. Brake fluid (Level, Leakage)
2. Brake pedal (Pedal to carpet clearance)
3. Parking brake lever (Play)
4. Brake Disc & Pads (Inspect)
5. Brake hoses & pipes (Leakage, Damage)
6. Brake Drums & Shoes (Inspect)
5. WHEEL
1. Tyres (Air pressure, Abnormal wear, Rotation)
2. Wheels (Inspect)
3. Front/Rear Wheel Bearings (Loose,Damage)
COST OF MATERIALS AND CONSUMABLES TO BE BORNE BY CUSTOMER
(10,000 KM or 12 MONTHS)
(CUSTOMER'S COPY)
6. FRONT AND REAR SUSPENSION
JOB
1. Suspension strut/shock absorber(Oil Leakage)
2. Suspension arms, Knuckle, Rear spring
(Damage, Loose)
3. All Nuts & Bolts (Tighten)
7. STEERING
1. Steering wheel (Play)
2. All Rods & Arms (Loose, Damage, Wear)
3. Power Steering System (Operation)
3
4. Steering gear box (Inspect)
5. Tilt steering (operation) (if equipped)
8. ELECTRICAL
1. Battery electrolyte (Level, Leakage)
2. Lighting system/Horn (Operation)
3. Wiring Harness Connections (Looseness)
4. Wiper (Operation)
9. BODY
1. All Latches, Hinges & Locks/Central Locking
(Operation/Lubrication)
2. All Chassis nuts & bolts (Tighten)
3. Seat belt (operation)
4. Seat latch, lever & knob (operation)
10. HEATING AND AIR CONDITIONING
1. Drive belt (Tension, Damage)
2. Check functioning of Recirculating flap
3. Check all Hose Joints
4. Check Compressor Mounting Bolts
5. Clean Condenser with low pressure water
6. A/C filter element (Inspect)
11. ROAD TEST
1. Operation of Brakes, clutch Gear
shifting and Speedometer
2. Body & Chassis noise
3RD. FREE INSPECTION COUPON
WHICHEVER COMES FIRST
(DEALER'S COPY)
Please see overleaf for special instructions
JOB
*MODEL CODES : ALTO-AOD308/308C/310/310C, CELERIO-AVH310/310C/208D,
CIAZ-AVB414/413D, EECO-MGA412/412C, ERTIGA-AVI414/413D,
GRAND VITARA XL7-JA627, GYPSY KING-MG413W,
NEW DZIRE-AZI412PN/413DN, NEW SWIFT-AZI412/413D,
NEW WAGONR-A1J310/310C/310L, OMNI-MT308, RITZ-A5E412/413D
(10,000 KM or 12 MONTHS)
*
Model Code
Chassis No. :
Engine No. :
Mileage
Date of Delivery
3
Date of Inspection
Registration No.
Service Dealer/Mass Code
Mechanic's Signature
Service Manager's Signature
Customer's Signature
