BERTL Exeptional Copystar CS 520i Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Wide 8.5" Color Touch Screen Control Panel
Advanced USB Host Interface
Fast Warm-up Time (30 seconds or less)
Efficient Duplex and Paper Handling
Outstanding ease-of-use for clearing misfeeds, loading paper, and changing toner
Scientifically enhanced long life consumables reduce the frequency of major component replacement and
downtime
Fast scan speeds in both full color and black & white
Scan to SMB, Scan to e-Mail, Scan to FTP, Scan to USB, WSD Scan, TWAIN Scan
2 GB RAM / Standard 160 GB Hard Disk Drive (HDD)
On-board Document Storage to secure and access commonly used documents
Optional Data Security Kit provides secure overwrite and encryption for Printing, Copying and Scanning
Security Watermarks prevents unauthorized copying
KX Driver allows users to access the unique features integrated into each CS MFP from one common print
driver
Offers Copystar's unique long-life technology and embedded HyPAS
Long Life Components and Consumables (Maximum Monthly Duty Cycle: 200,000 pages; Toner Yields:
34,000 Black pages, PM Schedule: 500,000 pages)
Section 508 Compliance
Three different optional finishers to choose from that offer advanced finishing
Maximum paper capacity of 4,200 pages
Energy Star and Restriction of Hazardous Substances (RoHS) Compliant
www.BERTL.com
Copystar CS 520i
52-ppm Monochrome
Print ▪ Copy ▪ Scan ▪ Fax
Key Buyer Benefits
Copyright © 2010 BERTL Inc.
