System - Dodge RAM 1500 1998 Owner's Manual

DR
VEHICLE THEFT SECURITY
DESCRIPTION
DESCRIPTION - VEHICLE THEFT/
SECURITY SYSTEM . . . . . . . . . . . . . . . . . . . . 1
DESCRIPTION - SENTRY KEY
IMMOBILIZER SYSTEM (SKIS) . . . . . . . . . . . . 1
DESCRIPTION - SENTRY KEY
IMMOBILIZER MODULE (SKIM) . . . . . . . . . . . . 1
OPERATION
OPERATION - VEHICLE THEFT/SECURITY
SYSTEM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
OPERATION - SENTRY KEY IMMOBILIZER
SYSTEM (SKIS) . . . . . . . . . . . . . . . . . . . . . . . . 2
OPERATION - SENTRY KEY IMMOBILIZER
MODULE (SKIM) . . . . . . . . . . . . . . . . . . . . . . . 2
VEHICLE THEFT SECURITY
DESCRIPTION
DESCRIPTION - VEHICLE THEFT/SECURITY

SYSTEM

The Vehicle Theft/Security System (VTSS) is
designed to protect against whole vehicle theft. The
system monitors the vehicle doors and ignition for
unauthorized operation.
The VTSS activates:
• Sounding of the horn
• Flashing of the park lamps
• Flashing of the head lamps
The Remote Keyless Entry (RKE) has 1 mode of
operation, CUSTOMER USAGE mode. The cus-
tomer usage mode provides full functionality of the
module and is the mode in which the RKE module
should be operating when used by the customer.
DESCRIPTION - SENTRY KEY IMMOBILIZER
SYSTEM (SKIS)
The Sentry Key Immobilizer System (SKIS) is
designed to provide passive protection against unau-
thorized vehicle use by preventing the engine from
operating while the system is armed. The primary
components of this system are the Sentry Key Immo-
bilizer Module (SKIM), the Sentry Key transponder,
the Vehicle Theft/Security System (VTSS) indicator
LED, and the Powertrain Control Module (PCM).
VEHICLE THEFT SECURITY
TABLE OF CONTENTS
page
VEHICLE THEFT SECURITY
DIAGNOSIS AND TESTING
VEHICLE THEFT SECURITY SYSTEM
STANDARD PROCEDURE
CONFIGURING A NEW MODULE / SWITCH
OPERATING MODES . . . . . . . . . . . . . . . . . . . . 3
SENTRY KEY IMMOBILIZER SYSTEM
INITIALIZATION . . . . . . . . . . . . . . . . . . . . . . . . 3
SENTRY KEY IMMOBILIZER SYSTEM
TRANSPONDER PROGRAMMING . . . . . . . . . . 4
SENTRY KEY IMMOBILIZER SYSTEM
INDICATOR LAMP
DESCRIPTION . . . . . . . . . . . . . . . . . . . . . . . . . . 5
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
The SKIM is installed on the steering column near
the ignition lock cylinder. The transponder is located
under the molded rubber cap on the head of the igni-
tion key. The VTSS indicator LED is located in the
instrument cluster.
DESCRIPTION - SENTRY KEY IMMOBILIZER
MODULE (SKIM)
The Sentry Key Immobilizer Module (SKIM) con-
tains a Radio Frequency (RF) transceiver and a cen-
tral processing unit, which includes the Sentry Key
Immobilizer System (SKIS) program logic. The SKIS
programming enables the SKIM to program and
retain in memory the codes of at least two, but no
more than eight electronically coded Sentry Key
transponders. The SKIS programming also enables
the SKIM to communicate over the Programmable
Communication Interface (PCI) bus network with the
Powertrain Control Module
DRBIII scan tool.
OPERATION
OPERATION - VEHICLE THEFT/SECURITY
SYSTEM
When in the Customer Usage mode of operation,
the system is armed when the vehicle is locked using
the:
• Power Door Lock Switches
• Remote Keyless Entry (RKE) Transmitter
• Key Cylinder Switches
8Q - 1
page
. . . . . . 3
(PCM), and/or the
