Fuse Name Symbol
F/PUMP
HORN
A/CON
VACUUM
VACUUM
PUMP
PUMP
HEADLAMP
DIPPED
BEAM
HEADLAMP
HIGH BEAM
FUSE
C/FAN
IG2
E3
ECU3
E2
ECU2
S1
SENSOR
S2
SENSOR2
Fuse rating
15A F/Pump 1 Relay
10A Horn Relay, B/Alarm Horn Relay
10A A/CON Relay
20A Vacuum Pump Relay
15A Headlamp High Beam
20A Headlamp Low Beam
40A C/FAN LO Relay, C/FAN HI Relay
Start Relay, Ignition Switch (W/O Button Start), PDM Relay Box (IG2 Relay) (With
40A
Button Start)
10A PCM
10A B3LA : PCM, Shut Off Valve #1/#2
C/FAN LO Relay, C/FAN HI Relay, A/CON Relay, Start Relay (G3LA, With ISG),
10A PCM, Oil Control Valve #1/#2 (IN/EX), Purge Control Solenoid Valve, Camshaft
Position Sensor #1/#2 (IN/EX)
10A G3LA/G4LA : PCM
