Maintenance
Fuse Name
Symbol
WIPER RR
POWER
1
POWER
OUTLET 1
OUTLET
A/BAG
MDPS
ACC
A/BAG IND
T/SIG
7
64
Fuse rating
15A
Rear Wiper Motor, Multifunction Switch
20A
Power Outlet
10A
SRS Control Module
7.5A
MDPS Unit
10A
BCM, Smart Key Control Module, Digital Clock, Auido, Power Outside Mirror Switch
10A
Instrument Cluster
10A
Side Repeater Lamp (LH/RH), Rear Combination Lamp (LH/RH)
Circuit Protected
